 Home > Products > Racks > Wallmount Rack Enclosures

 Part Numbers

Wallmount Rack Enclosures

 IP11001 to 14

This is a picture of a wallmount rack enclosure 18RU
  • Double section welded frame structure
  • Easy operation and maintaining at the back
  • 19” standard installation
  • Removable side panels
  • Side locks are optional
  • Easy installing nd maintaining;
  • Cable entry at the top cover & bottom panels
  • 120mm fan optional
  • Turning angle of front door is above 180 degrees
  • Turning angle of rear door is above 90 degrees
  • Swing frame at rear with cable entry zones optional



Frame Structure

 Double section welded frame structure
 Easy operation and maintaining at the back
 19” standard installation
 Removable side panels
 Side locks are optional
 Easy installing and maintaining

Cable Entry Zones

 Cable entry at the top cover & the bottom panel
 Cable entry in the optional swing frame in multiple zones
 Cooling
 120mm fan optional

Door Opennings

 Turning angle of front door is above 180 degrees
 Turning angle of rear door is above 90 degrees

Material

 SPCC cold rolled steel
 Thickness:mounting profile 2.0mm, mounting angle 1.5mm, others 1.2mm

Surface Finish

 Degreasing
 Pickling
 Phosphoric
 Powder coated black of beige/grey

Degree of protection

 IP20

Loading Capacity

 Static loading of 60KG (depending on size)



This is a picture of a wallmount rack enclosure 18RU

RU

Capacity

Overall Width

(mm)

Depth without

swing frame (mm)

Depth with swing

frame (mm)

Overall Height

(mm)

Part Number

6 600  450 550 368 IP11001
9 501 IP11002
12 635 IP11003
15 769 IP11004
18 901 IP11005
22 1082 IP11006
27 1304 IP11007
6 600 600 650 368 IP11008
9 501 IP11009
12 635 IP11010
15 769 IP11011
18 901 IP11012
22 1082 IP11013
27 1304 IP11014

Door Options

 Toughened Glass
 Toughened Glass with Perforated sides strips

Material

 SPCC cold rolled steel
 Thickness:mounting profile 2.0mm, mounting angle 1.5mm, others 1.2mm

Surface Finish

 Degreasing
 Pickling
 Phosphoric
 Powder coated black of beige/grey

Degree of protection

 IP20

Loading Capacity

 Static loading of 60-100KG (depending on size)

Colours

 Black (RAL9004)
 Grey/Beige (RAL7035)

 Brochures

OIPG 19inch wallmount rack brochure  PDF  1,305 KB 10/05/2014
